Name: Creamsource Vortex8 Soft 650W Colour
Brand: Creamsource
SKU: CS K-CSV-8S-ESS
Price: 8250.0 AUD
Availability: InStock

Description

Discover the Vortex8 Soft (V8S), the 2x1 LED lighting system for professionals seeking versatility and quality. As the softer sibling to the Vortex8 hard panel, it's designed with the same build-quality and user-friendly interface, integrating an RRGBBW colour engine, power supply, and antennas into a sleek, robust design. A 110° beam produces 58,200lumens and 2,340lux @3m (5600K, Open Face). This fixture has a CCT range from 2200k to 15000k and eight independently controllable zones.

Features

High Output Soft Light: 650W (V8S) of output, throwing 58,200lumens for V8S, 110º beam angle.
Customisable Arrays: Vortex Softs can be mixed with Vortex hard panels using LNX and other mounting systems.
On the Go: A 48V DC power input means you can go battery powered when on location, and an IP65 rating ensures you'll stay lit even when the storms roll in.
CreamOS Integration: Shares CreamOS with other Vortex products, enabling consistent control and easy integration into existing lighting rigs.
Light Source: RRGBBW (red+deep red, green, blue+royal blue, white)

Specs

Power	650W
Light Zones (Pixels)	8
Material	Aluminium/Technopolymer
Light Source	RRGBBW LED
Colour Range	CCT: 2200 - 15000K, PLUS/MINUS GREEN, HUE/SATURATION, XY, GELS, DIRECT RGBW, EFFECTS
CRI / TLCI	Typical 95
Beam Angle	110° (Half Peak Angle)
Tilt Angle	360°
Photometrics Open Face 3200K:	19,500 lx / 1,812 fc @ 1m / 3.3ft 5,140 lx / 478 fc @ 2m / 6.6ft 2,400 lx / 223 fc @ 3m / 9.8ft 1,410 lx / 131 fc @ 4m / 13.1ft 920 lx / 85 fc @ 5m / 16.4 ft 670 lx / 62 fc @ 6m / 19.7 ft
Photometrics Open Face 3200K: Open Face 5600K:	19,100 lx / 1,774 fc @ 1m / 3.3ft 5,010 lx / 465 fc @ 2m / 6.6ft 2,340 lx / 217 fc @ 3m / 9.8ft 1,370 lx / 127 fc @ 4m / 13.1ft 900 lx / 84 fc @ 5m / 16.4 ft 650 lx / 60 fc @ 6m / 19.7 ft
Mounting	8x3/8” threaded rigging points, 4x LNX sockets
Yoke	Removable quick release yoke
Filter Rails	2 Filter Rails for Secondary Lenses, Diffusers, Accessories
User interface	High Precision Digital Magnetic Encoder, Backlit Keypad, Colour LCD Display
Dimming	0-100% with High Resolution, Super-Smooth Low End Mode
High Speed Capability	Over 5000fps Flicker Free in High Speed Mode
Synchronization	Sync Input for Triggering and Syncing to Camera Shutter
Max Ambient Temperature	40°C / 104°F
Cooling	Low noise variable speed fans
Estimated LED Lifespan	50,000hrs (L70)
Input (AC)	100-240V AC, 50/60Hz, Max 6.6A. Neutrik powerCON TRUE1 connector
Input (DC)	48V DC, Max 13.75A. Can run at 100% brightness on DC input
Protection Class	IP65
Weight	14.0kg / 30.9lb (Excluding yoke) 16.0kg / 35.3lb (Including yoke)

Dimensions	690 x 380 x 121 mm / 27.2 x 15 x 4.8 in. (Excluding Yoke) 831 x 551 x 164 mm / 32.7 x 21.7 x 6.4 in. (Including Yoke)
Warranty	3 years on fixtures 12 months on accessories
Certifications	Pending: CE, UKCA, RCM, CSA, ETL, FCC
Control	On-Board Interface, DMX via standard 5-pin XLR connectors, Wired Remote Control Accessory, Integrated LumenRadio TimoTwo with BLE, etherCON, USB Type A

What's In The box

More Info

The Vortex8S is a dedicated soft source that blends efficiency and performance with its 650W output, enveloping your space in beautiful full-spectrum soft light. Whether it's for a space-constrained studio setup or the demanding conditions of outdoor broadcasts, the Vortex8 Soft is your go-to lighting solution. Its 48V DC input ensures easy transition to battery power when the action moves off-grid.

Built to endure the rigours of any shooting environment, the Vortex8 Soft is resilient with an IP65 rating that assures dependability even when weather conditions are far from ideal. Powered by CreamOS, it integrates smoothly with other Vortex products, allowing for consistent control and effortless incorporation into existing setups.
