Reflect Colour is the ultimate lighting fixture for all your lighting needs
Versatile PerformanceBacklit Cyclorama, Key light, Backlight, Fill light, Set lighting, and Foot light – All effortlessly achieved with Reflect Colour.
Compact Powerhouse
Reflect Colour can be mounted almost anywhere and will appear very discrete in the
studio ceiling, Despite of punching out up to 5500 Lumens of white light the 2-foot
linear fixture weighs only 3,6Kg/7,9lbs.
From semihard to supersoft
Seamlessly transitioning from semihard to supersoft illumination, Reflect Colour offers
unmatched versatility in lighting design. At its core is a built-in colour mixing chamber,
meticulously engineered to deliver exquisite mixed colour rendition. This chamber,
paired with a steep silver-coated semi-diffused reflector, precisely sculpts a controlled
semihard 100 x 60-degree beam, perfectly suited for the 16:9 format. Sliding in the
included secondary diffuser transforms the beam into a circular 120-degree supersoft
beam.
Real colours
Explore the sophisticated colour capabilities in the richness of deep blue, the intensity
of the double Deep Ruby Red, the lushness of medium green, and the purity of warm
and cold white lighting options, meticulously calibrated for optimal performance and
the richest skin tones.
A full Lighting system Compact and silent
Reflect Colour is the latest addition to an ever-growing range of studio lighting products
made by Brother, Brother & Sons and will fill in the blanks where full colour Capability is
needed in one product. As all the other BB&S product ranges CBL, CFL, Reflect Single
and Bi-colour products the Reflect Colour is completely silent ( no fans ), compact yet
powerful & built to last.
Control
The Reflect Colour is fully controllable via RDM/DMX
512 and can be powered from 2 different sources;
The Reflect Colour 6-unit PSU or the Reflect Colour
DMX Lighting track PSU.
Power Options -Reflect Colour 6-unit hybrid PSU
Reflect Colour 6-unit hybrid PSU (DMX512/RDM)
Power & DMX/RDM for up to: 6x Reflect Colour
4-Pin Power & Data Cables available in:
0,3m, 0,8m, 1,2m & 2m.
Reflect Colour Onetrack box adaptor
Reflect Colour Onetrack box adaptor DMX/RDM
Power & DMX/RDM for: 1x Reflect Colour
Power Supply 48V DC
• AC: 110-240V 50/60Hz
• Max Power Consumption 1 unit: 80W
• Max Power Consumption 6 units: 480W
LEDs
• Premium Double Deep Ruby Red LEDS
• Premium Medium Green LEDS
• Premium Deep Blue LEDS
• Premium Double Warm White LEDS
• Premium Double Cold White LEDS
Control / Setup
• DMX512/RDM
16-Bit dimming 0-100%
• All operation & setup over DMX/RDM
Weight & Dimensions
L: 610mm/2ft.
H: 118mm/6.4”
W: 110mm/4,3’’
Weight: 3,6kg/7,9lbs
Temperture Range
Ambient operation from
-20° to 40°C/-4° to 104° F
IP Rating
• IP20
BB&S Reflect Color - 1 unit (SKU#3920)
Includes 1x Front Diffuser
Download BB&S Reflect Colour Datasheet
