Vari-Lite VL600 Acclaim Zoomspot

We work with you to find the best pricing solution for your needs.

Colour: Black
Black
White

The Vari-Lite VL600 Acclaim Zoomspot is an RGBL LED ellipsoidal profile fixture combining high-output 500/650 W-equivalent performance with integrated manual zoom, focus and framing. Designed for schools, theatres and houses of worship, it brings precise key-light and gobo projection capabilities to venues with limited space.

With 25–50° manual zoom, a four-blade shutter system and an optional angle-adjusting B-size metal gobo holder, the Zoomspot can illuminate performers, restrict spill around scenery and project textured patterns. The height-adjustable yoke helps reduce the installed footprint where trim height is limited, while the red, green, blue and lime mixing engine offers colour consistency with other VL600 Acclaim fixtures. Available in black and white.

Features
  • 500/650 W-equivalent LED Zoomspot profile designed for front lighting, highlight and gobo projection.
  • 150 W RGBL multichromatic LED engine with matching colour control to other VL600 Acclaim luminaires.
  • Integrated 25–50° manual zoom for accurate beam-angle adjustment without changing lens tubes.
  • Manual focus allows the projected image to be sharp or intentionally soft.
  • Four-blade manual framing shutters restrict spill and precisely shape light around subjects and scenery.
  • Optional adjustable-size B gobo holder supports industry-standard metal or glass gobos and precise alignment.
  • Height-adjustable yoke helps achieve suitable mounting positions when rigging height is limited.
  • Electronic 8/16-bit dimming with Square Law, Linear and S-curve settings.
  • 5-pin DMX512-A/RDM in/thru and advanced-feature manual preset operation.
  • Standard, Studio and Whisper fan modes for acoustically sensitive stages.
  • Selectable colour calibration and LED refresh frequency from 500 to 4,000 Hz.
  • Available in black or white housings, with accessory holder, gel frame and iris options.
Specs
LED Multichromatic Light Engine - RGBL
Source Max Power Consumption 150 W
LED Refresh Rate 500 Hz to 4000 Hz
Dimming Electronic 8-bit / 16-bit
Dimmer Curves Square Law (Default), Linear, S-Curve
Strobe Speed 0 - 30 Hz
Lens Size 111 mm (4.4 in)
Zoom Range 25 - 50°
Zoom Control Manual control
Focus Manual control
Output Lumens Beam - 6,500, Field - 8,500
CRI Ra (7100 K) 84
CRI Ra (5600 K) 84
CRI Ra (3200 K) 84
TM-30 (7100 K) Rf 79 / Rg 102
TM-30 (5600 K) Rf 80 / Rg 102
TM-30 (3200 K) Rf 78 / Rg 109
CQS (7100 K) 80
TLCI (7100 K) 77
TLCI (5600 K) 78
TLCI (3200 K) 74
Color Mixing RGBL
Color Mixing Control Open Source
Color Calibration Selectable On/Off
Shutter 4 blade manual framing shutters
Max Output Power Consumption 170 W
Power Connection TrueOne Compatible - In / Thru
Power Cable Not included - input connector only
Input Voltage 100–240 VAC, 50 / 60 Hz
Standby Power 8.8 W
Supported Protocols DMX512-A (RDM)
DMX Modes (16-Bit) 11 Channels
DMX Modes (8-Bit) 8 Channels
Data Connections 5-Pin XLR Input and Thru
Manual Preset Mode Advanced Feature local control
Base Noise Level 21 dB @ 1 m (3.3 ft)
Standard Mode 42.6 dB
Studio Mode 37 dB
Whisper Mode 33.2 dB
Fan Mode Continuous (On) / Auto Ramping
Fan Level Preset Standard, Studio, Whisper
Cooling System Type Hybrid sealed liquid and forced air system
Yoke Double clutch locking yoke >270° Swivel Yoke M12 (1/2") Centre hole
Fixture Mounting/Hanging Orientation Hanging - Floor - Side
Secondary Safety Wire Point 1 x Safety point located on rear of fixture housing
Photometric Reports and IES Files https://www.vari-lite.com/global/products/acclaim-led-zoomspot
PHYSICAL SPECIFICATIONS
Housing Dimensions 190 × 353 × 522 mm
Dimensions Including Yoke 398 × 268 × 522 mm
Fixture Weight 8 kg
Ingress Protection IP20
Operating Temperature −10–40°C
Body Colours Black, White
Manufacturer Order Codes 64511-002 (Black); 64511-102 (White)
COMPATIBLE ACCESSORIES
Accessory Holder + Gel Frame 64511-011 (Black) / 64511-111 (White)
B-Size Adjustable Gobo Holder 64511-012
Adjustable Iris 64511-013
Six Gel Frames 65411-900 (Black) / 65411-901 (White)
SOURCES
Official Manufacturer Datasheet https://vari-lite.s3.eu-west-1.amazonaws.com/datasheets/vl600-acclaim-zoomspot.pdf
More info

The Acclaim Zoomspot combines a profile engine, adjustable zoom and manual focus in one housing. Its 25–50° range and flat, even field help light performers or highlight scenery, while the shutter system allows the operator to trim the edges without adding a separate framing accessory.

An optional angle-adjusting B-size gobo holder enables pattern projection. Together with manual focus and framing shutters, this allows both sharply defined shapes and softly focused textured looks.

The 150 W RGBL engine uses red, green, blue and lime mixing and selectable colour calibration. The manufacturer provides colour-rendering data at 3,200 K, 5,600 K and 7,100 K in its technical specification sheet.

The yoke is adjustable to place the fixture closer to the suspension point, which helps in smaller theatres with limited trim height. Standard, Studio and Whisper fan modes, 8-bit/16-bit dimming and 5-pin DMX/RDM make it suitable for traditional stage-lighting control.

The manufacturer's fixture weight is 8 kg. Physical product size, optional accessories, mounting conditions and connection requirements should be confirmed in the official manual before installation; the FrameLight shipping weight is a separate, estimated volumetric allowance.
