Creamsource Vortex24 Colour

Special Ends {timer}


Meet the Vortex24, a dynamic 2x3 lighting system tailored for those seeking expansive coverage and powerful output. Building on the foundation of the Vortex8, the Vortex24 amplifies output threefold, while its larger form factor reduces the need for multiple units and simplifies rigging, especially on Elevated Work Platforms (EWP) or Condors.


  • Pixel Precision: 24 pixel zones for lighting effects like fire and motion with smooth dimming across all intensities, all while maintaining colour accuracy.
  • Powerfully Efficient: Draws 1950W power, and includes a 'House Power' setting for 15A circuit operation.
  • Compact Design: Built-in ballast facilitating easier storage on carts and integration into truck packages.
  • Networking Simplicity: Equipped with dual Ethernet ports with a built-in Gigabit switch, enabling single-cable runs and daisy-chaining of units.
  • Quick Adjustments: A front latch system enables swift swaps of diffusers and accessories and includes a medium flat diffuser for immediate light softening.
  • Light Source: RRGBBW (red+deep red, green, blue+royal blue, white), throwing 90,000lumens at 3m (5600K, naked) with a 20º beam angle


Power 1950W
Light Zones (Pixels) 24
Material Aluminium/Technopolymer
Light Source  RRGBBW LED
CRI / TLCI  Typical 95
Beam Angle  20° (Half Peak Angle)
Tilt Angle  360°
Photometrics Native 3200K/5600K: 96,350 lx / 8,951 fc @ 1m / 3.3 ft
48,800 lx / 4,534 fc @ 2m / 6.6 ft
27,560 lx / 2,560 fc @ 3m / 9.8 ft
16,990 lx / 1,578 fc @ 4m / 13.1 ft
11,350 lx / 1,054 fc @ 5m / 16.4 ft
8,150 lx / 757 fc @ 6m / 19.7 ft
Photometrics Diffuser 3200K/5600K: 26,940 lx / 2,503 fc @ 1m / 3.3 ft
7,960 lx / 740 fc @ 2m / 6.6 ft
3,730 lx / 347 fc @ 3m / 9.8 ft
2,120 lx / 197 fc @ 4m / 13.1 ft
1,410 lx / 131 fc @ 5m / 16.4 ft
1,010 lx / 94 fc @ 6m / 19.7 ft
Mounting  8x3/8” threaded rigging points, 4x LNX sockets
Yoke  Removable quick release yoke
Filter Rails  2 Filter Rails for Secondary Lenses, Diffusers, Accessories
User interface  High Precision Digital Magnetic Encoder, Backlit Keypad, Colour LCD Display
Dimming  0-100% with High Resolution, Super-Smooth Low End Mode
High Speed Capability  Over 5000fps Flicker Free in High Speed Mode
Synchronization  Sync Input for Triggering and Syncing to Camera Shutter
Max Ambient Temperature  40°C / 104°F
Cooling  Low noise variable speed fans
Estimated LED Lifespan  50,000hrs (L70)
Input (AC)  110-240V AC, 50/60Hz, Max 17.7A. Neutrik powerCON TRUE1 connector
Input (DC)  N/A
Protection Class  IP65
Weight  46.5kg / 102.5lb (Excluding yoke)
53.5kg / 117.9lb (Including yoke)
Dimensions  971 x 686 x 258 mm / 38.2 x 27 x 10.2 in. (Excluding yoke)
1333 x 971 x 258 mm / 52.5 x 38.2 x 10.2 in. (Including yoke)
Warranty 3 years on fixtures
12 months on accessories
Certifications  Pending: CE, UKCA, RCM, CSA, ETL, FCC
Control  On-Board Interface, DMX via standard 5-pin XLR connectors, Wired Remote Control
Accessory, Integrated LumenRadio TimoTwo with BLE, 2x etherCON, USB Type A



What's In The box

Creamsource Vortex24 Colour
1x Head
1x Yoke
1x Diffusion
1x Power Cable



More Info

Designed with 24 directional pixel zones, the Vortex24 allows for complex lighting effects like replicating the dynamics of fire or motion, with seamless dimming across intensities all while maintaining colour accuracy, free from drift. The Vortex24's efficient design draws 1950W, making it compatible with standard circuits and featuring a 'House Power' mode for 15A circuits. The integration of a built-in ballast means easier storage and transport, allowing for streamlined packing in lighting carts and trucks, optimising your workflow on the go.

Network setup is a breeze with dual Ethernet ports and a Gigabit switch, supporting single-cable runs and efficient daisy-chaining of units. Featuring a front latch filter system for fast changes of diffusers and accessories, the Vortex24 also ships with a medium flat diffuser for instant light softening — no extra purchases necessary.



 Download Creamsource Vortex24 Colour Datasheet
