SPX1535LT

Vari-Lite SPX Zoom Lens Tube

We work with you to find the best pricing solution for your needs.

Zoom Range: 15°–35°

Vari-Lite SPX Zoom Series Lens Tubes provide two professional variable-angle optics for compatible theatrical profile light engines. Choose the 15–35° model (SPX1535LT) for general profile work or the 25–50° model (SPX2550LT) for wider-angle applications. Designed for use with suitable LED or incandescent sources, the SPX Zoom Series supports gobo projection and flexible beam sizing without exchanging a complete fixture.

The SPX Quick Change tool-free slot-and-lock attachment allows the lens tube to be changed without the complicated removal of the shutter gate. A light-tight gel house limits stray light and is designed to promote airflow for improved filter life. Confirm lens-to-light-engine compatibility before ordering.

Features
  • Professional SPX Zoom lens-tube design for compatible LED and incandescent theatrical profile light engines.
  • Two focal ranges available: 15–35° (SPX1535LT) or 25–50° (SPX2550LT).
  • Quick Change slot-and-lock system enables tool-free lens exchange.
  • Lens tubes can be interchanged with suitable fixed lenses without removing the shutter gate assembly.
  • Light-tight gel housing helps prevent light leaks around the colour-media area.
  • Ventilated gel house encourages airflow to help extend colour filter life.
  • Designed for accurate focus, gobo projection and versatile beam angle selection.
Specs
OPTIONS
SPX 15°–35° VAR SPX1535LT
SPX 25°–50° VAR SPX2550LT
OPTICAL DESIGN
System SPX variable zoom lens
Zoom Ranges 15°–35° or 25°–50°
Attachment Quick Change tool-free slot-and-lock
Light Control Light-tight ventilated gel housing
MANUFACTURER
Official Page https://www.vari-lite.com/global/products/fixed-angle-lens-tubes
More info

The SPX Zoom Series provides beam-angle flexibility from a lens tube rather than requiring a different profile light engine. Use the 15–35° option for general theatrical work or the 25–50° version when a wider wash or closer throw is needed.

Both models feature Vari-Lite's Quick Change slot-and-lock interface. This allows compatible lens tubes to be changed without dismantling the shutter gate, simplifying changeovers when a production's throw distances or coverage requirements change.

The gel housing is designed to be light-tight while promoting airflow around inserted colour media, reducing unwanted light leakage and helping prolong gel life. Vari-Lite states that the SPX Zoom Series supports both LED and incandescent sources.

Always check compatibility with the specific profile light engine and the lens-tube mount. Manufacturer part numbers are SPX1535LT and SPX2550LT; the lens tube is a separate component from the light engine.
